2419 - Foret à plaquette carbure brasée série courte angle de pointe 90°

Family 2419

Brazed carbide insert drill bit 6° cut 90° tip angle
Right cutting : 6°
Sharpening : AF1
Body : High-speed steel - Carbide insert K20

Dry cutting

Features

Dry cutting
Drilling

Machined materials

Non ferrous metals
Aluminium
Carbon fibers
Graphite

Technical drawing

Schéma technique
Réf. D1 D2 L2 L1 Z -
2419--0250 2.5 2.5 30.0 57.0 2
2419--0260 2.6 2.6 30.0 57.0 2
2419--0270 2.7 2.7 33.0 61.0 2
2419--0280 2.8 2.8 33.0 61.0 2
2419--0290 2.9 2.9 33.0 61.0 2
2419--0300 3.0 3.0 33.0 61.0 2
2419--0310 3.1 3.1 36.0 65.0 2
2419--0320 3.2 3.2 36.0 65.0 2
2419--0330 3.3 3.3 36.0 65.0 2
2419--0340 3.4 3.4 39.0 70.0 2
2419--0350 3.5 3.5 39.0 70.0 2
2419--0360 3.6 3.6 39.0 70.0 2
2419--0370 3.7 3.7 39.0 70.0 2
2419--0380 3.8 3.8 43.0 75.0 2
2419--0390 3.9 3.9 43.0 75.0 2
2419--0400 4.0 4.0 43.0 75.0 2
2419--0410 4.1 4.1 43.0 75.0 2
2419--0420 4.2 4.2 43.0 75.0 2
2419--0430 4.3 4.3 47.0 80.0 2
2419--0440 4.4 4.4 47.0 80.0 2
2419--0450 4.5 4.5 47.0 80.0 2
2419--0460 4.6 4.6 47.0 80.0 2
2419--0470 4.7 4.7 47.0 80.0 2
2419--0480 4.8 4.8 52.0 86.0 2
2419--0490 4.9 4.9 52.0 86.0 2
2419--0500 5.0 5.0 52.0 86.0 2
2419--0510 5.1 5.1 52.0 86.0 2
2419--0520 5.2 5.2 52.0 86.0 2
2419--0530 5.3 5.3 52.0 86.0 2
2419--0540 5.4 5.4 57.0 93.0 2
2419--0550 5.5 5.5 57.0 93.0 2
2419--0560 5.6 5.6 57.0 93.0 2
2419--0570 5.7 5.7 57.0 93.0 2
2419--0580 5.8 5.8 57.0 93.0 2
2419--0590 5.9 5.9 57.0 93.0 2
2419--0600 6.0 6.0 57.0 93.0 2
2419--0610 6.1 6.1 63.0 101.0 2
2419--0620 6.2 6.2 63.0 101.0 2
2419--0630 6.3 6.3 63.0 101.0 2
2419--0640 6.4 6.4 63.0 101.0 2
2419--0650 6.5 6.5 63.0 101.0 2
2419--0660 6.6 6.6 69.0 109.0 2
2419--0670 6.7 6.7 69.0 109.0 2
2419--0680 6.8 6.8 69.0 109.0 2
2419--0690 6.9 6.9 69.0 109.0 2
2419--0700 7.0 7.0 69.0 109.0 2
2419--0710 7.1 7.1 69.0 109.0 2
2419--0720 7.2 7.2 69.0 109.0 2
2419--0730 7.3 7.3 69.0 109.0 2
2419--0740 7.4 7.4 69.0 109.0 2
2419--0750 7.5 7.5 69.0 109.0 2
2419--0760 7.6 7.6 75.0 117.0 2
2419--0770 7.7 7.7 75.0 117.0 2
2419--0780 7.8 7.8 75.0 117.0 2
2419--0790 7.9 7.9 75.0 117.0 2
2419--0800 8.0 8.0 75.0 117.0 2
2419--0810 8.1 8.1 75.0 117.0 2
2419--0820 8.2 8.2 75.0 117.0 2
2419--0830 8.3 8.3 75.0 117.0 2
2419--0840 8.4 8.4 75.0 117.0 2
2419--0850 8.5 8.5 75.0 117.0 2
2419--0860 8.6 8.6 81.0 125.0 2
2419--0870 8.7 8.7 81.0 125.0 2
2419--0880 8.8 8.8 81.0 125.0 2
2419--0890 8.9 8.9 81.0 125.0 2
2419--0900 9.0 9.0 81.0 125.0 2
2419--0910 9.1 9.1 81.0 125.0 2
2419--0920 9.2 9.2 81.0 125.0 2
2419--0930 9.3 9.3 81.0 125.0 2
2419--0940 9.4 9.4 81.0 125.0 2
2419--0950 9.5 9.5 81.0 125.0 2
2419--0960 9.6 9.6 87.0 133.0 2
2419--0970 9.7 9.7 87.0 133.0 2
2419--0980 9.8 9.8 87.0 133.0 2
2419--0990 9.9 9.9 87.0 133.0 2
2419--1000 10.0 10.0 87.0 133.0 2
2419--1020 10.2 10.2 87.0 133.0 2
2419--1050 10.5 10.5 87.0 133.0 2
2419--1100 11.0 11.0 94.0 142.0 2
2419--1120 11.2 11.2 94.0 142.0 2
2419--1150 11.5 11.5 94.0 142.0 1
2419--1200 12.0 12.0 101.0 151.0 1
2419--1220 12.2 12.2 101.0 151.0 1
2419--1250 12.5 12.5 101.0 151.0 1
2419--1300 13.0 13.0 101.0 151.0 1
2419--1350 13.5 13.5 108.0 160.0 1
2419--1400 14.0 14.0 108.0 160.0 1
2419--1450 14.5 14.5 114.0 169.0 1
2419--1500 15.0 15.0 114.0 169.0 1
2419--1550 15.5 15.5 120.0 178.0 1
2419--1600 16.0 16.0 120.0 178.0 1
