4044 - Fraise de rainage - pliage - chanfreinage pour plastiques, PVC, bois, HPL, matériaux phénoliques

Family 4044

4044 - Cutters for slot cutting - folding - chamfering

Very good surface finish

solid carbide, High rigidity

AVAILABLE IN RINGED VERSION FOR TOOLS WITH Ø6 SHANK.
The reference with ring has a "-B" at the end of the usual reference.
Example:
Standard part no. without ring: 4044--10P0020-090
Part no. with ring: 4044--10P0020-090-B
Lead time: 48 hours

From 81,50 €

Features

Milling
Slotting
Milling with chamfer

Machined materials

Composite wood products
Hardwoods
Softwoods
Expanded pvc
Compact laminates
Phenolic materials
Thermosetting plastics
Thermoplastics

Possible materials

Aluminium faced composite panels

Technical drawing

Schéma technique
Réf. D1 D2 D3 L3 L2 L1 α Z -
4044--08P0020-090 8.0 8.0 0.2 3.9 - 50.0 90° 2
4044--10P0020-090 10.0 6.0 0.2 4.9 25.0 50.0 90° 2
4044--12P0020-090 12.0 12.0 0.2 5.9 - 50.0 90° 2
4044--16P0020-090 16.0 8.0 0.2 7.9 12.0 50.0 90° 2
