61530A - Foret Carbure Monobloc Haute performance

Famille 61530A

Foret carbure monobloc 5xD
Trou d'huile
Affûtage AF24 queue cylindique
Revêtement ALTIN-SIT

Usinage sous lubrification

Caractéristiques

Usinage sous lubrification
Perçage

Matières usinées

Aciers
Aciers inoxydables
Titane
Fontes
Aluminium

Schéma technique

Schéma technique
Réf. D1 D2 L2 L1 Z -
61530A0400 4.0 6.0* 74.0 36.0 1
61530A0410 4.1 6.0* 74.0 36.0 1
61530A0420 4.2 6.0* 74.0 36.0 1
61530A0425 4.25 6.0* 74.0 36.0 1
61530A0430 4.3 6.0* 74.0 36.0 1
61530A0440 4.4 6.0* 74.0 36.0 1
61530A0450 4.5 6.0* 74.0 36.0 1
61530A0460 4.6 6.0* 74.0 36.0 1
61530A0470 4.7 6.0* 74.0 36.0 1
61530A0475 4.75 6.0* 74.0 36.0 1
61530A0480 4.8 6.0* 82.0 44.0 1
61530A0490 4.9 6.0* 82.0 44.0 1
61530A0500 5.0 6.0* 82.0 44.0 1
61530A0510 5.1 6.0* 82.0 44.0 1
61530A0520 5.2 6.0* 82.0 44.0 1
61530A0525 5.25 6.0* 82.0 44.0 1
61530A0530 5.3 6.0* 82.0 44.0 1
61530A0540 5.4 6.0* 82.0 44.0 1
61530A0550 5.5 6.0* 82.0 44.0 1
61530A0560 5.6 6.0* 82.0 44.0 1
61530A0570 5.7 6.0* 82.0 44.0 1
61530A0575 5.75 6.0* 82.0 44.0 1
61530A0580 5.8 6.0* 82.0 44.0 1
61530A0590 5.9 6.0* 82.0 44.0 1
61530A0600 6.0 6.0 82.0 44.0 1
61530A0610 6.1 8.0* 91.0 53.0 1
61530A0620 6.2 8.0* 91.0 53.0 1
61530A0625 6.25 8.0* 91.0 53.0 1
61530A0630 6.3 8.0* 91.0 53.0 1
61530A0640 6.4 8.0* 91.0 53.0 1
61530A0650 6.5 8.0* 91.0 53.0 1
61530A0660 6.6 8.0* 91.0 53.0 1
61530A0670 6.7 8.0* 91.0 53.0 1
61530A0675 6.75 8.0* 91.0 53.0 1
61530A0680 6.8 8.0* 91.0 53.0 1
61530A0690 6.9 8.0* 91.0 53.0 1
61530A0700 7.0 8.0* 91.0 53.0 1
61530A0710 7.1 8.0* 91.0 53.0 1
61530A0720 7.2 8.0* 91.0 53.0 1
61530A0725 7.25 8.0* 91.0 53.0 1
61530A0730 7.3 8.0* 91.0 53.0 1
61530A0740 7.4 8.0* 91.0 53.0 1
61530A0750 7.5 8.0* 91.0 53.0 1
61530A0760 7.6 8.0* 91.0 53.0 1
61530A0770 7.7 8.0* 91.0 53.0 1
61530A0775 7.75 8.0* 91.0 53.0 1
61530A0780 7.8 8.0* 91.0 53.0 1
61530A0790 7.9 8.0* 91.0 53.0 1
61530A0800 8.0 8.0 91.0 53.0 1
61530A0810 8.1 10.0* 10.0 61.0 1
61530A0820 8.2 10.0* 10.0 61.0 1
61530A0825 8.25 10.0* 10.0 61.0 1
61530A0830 8.3 10.0* 10.0 61.0 1
61530A0840 8.4 10.0* 10.0 61.0 1
61530A0850 8.5 10.0* 10.0 61.0 1
61530A0860 8.6 10.0* 10.0 61.0 1
61530A0870 8.7 10.0* 10.0 61.0 1
61530A0875 8.75 10.0* 10.0 61.0 1
61530A0880 8.8 10.0* 10.0 61.0 1
61530A0890 8.9 10.0* 10.0 61.0 1
61530A0900 9.0 10.0* 10.0 61.0 1
61530A0910 9.1 10.0* 10.0 61.0 1
61530A0920 9.2 10.0* 10.0 61.0 1
61530A0930 9.3 10.0* 10.0 61.0 1
61530A0940 9.4 10.0* 10.0 61.0 1
61530A0950 9.5 10.0* 10.0 61.0 1
61530A1000 10.0 10.0 10.0 61.0 1
61530A1020 10.2 12.0* 11.0 71.0 1
61530A1050 10.5 12.0* 11.0 71.0 1
61530A1080 10.8 12.0* 11.0 71.0 1
61530A1100 11.0 12.0* 11.0 71.0 1
61530A1150 11.5 12.0* 11.0 71.0 1
61530A1180 11.8 12.0* 11.0 71.0 1
61530A1200 12.0 12.0 11.0 71.0 1
61530A1250 12.5 14.0* 12.0 77.0 1
61530A1270 12.7 14.0* 12.0 77.0 1
61530A1300 13.0 14.0* 12.0 77.0 1
61530A1350 13.5 14.0* 12.0 77.0 1
61530A1370 13.7 14.0* 12.0 77.0 1
61530A1400 14.0 14.0 12.0 77.0 1
61530A1450 14.5 16.0 13.0 83.0 1
61530A1470 14.7 16.0 13.0 83.0 1
61530A1500 15.0 16.0 13.0 83.0 1
61530A1550 15.5 16.0 13.0 83.0 1
61530A1570 15.7 16.0 13.0 83.0 1
61530A1600 16.0 16.0 13.0 83.0 1
* Queue renforcée
